Vaaku V-Smart
V-Smart 105060
A smart lithium UPS built with the safest LiFePO4 technology, offering up to 5 hours of backup, fast charging, lightweight design, and eco-friendly performance, ideal for homes and small offices.
Key Features:
- Dimensions (HxLxW): 410 x 254 x 223 mm
- Capacity: 850W / 1050VA
- Full Load: 850W
- DC Voltage: 12.8 Vdc
- Battery Type: LiFePO4
- Battery Capacity (Wh): 768Wh (60Ah)
- Warranty: 66 Months on Battery, 36 Months on Electronics
Input :
- Input Voltage Range (Normal Mode): 100V–290V
- Input Voltage Range (UPS Mode): 180V–270V
- Frequency: 50Hz
- Transfer Time (UPS Mode): <12ms
Output :
- Output Voltage (AC): 220Vrms
- Frequency: 50Hz
- Waveform: Sine wave
- Battery Charging: 15A
- Weight: 21 Kg
- Protections: Overload, Over/Under Voltage, Battery Deep Discharge, Battery Overcharge & Over Temperature
V-Smart 1050105
An extended backup version of 105060, designed for users needing longer power support with a higher 105Ah lithium battery and seamless pure sine wave output.
Key Features:
- Dimensions (HxLxW): 506 x 254 x 223 mm
- Capacity: 850W / 1050VA
- Full Load: 850W
- DC Voltage: 12.8 Vdc
- Battery Type: LiFePO4
- Battery Capacity (Wh): 1344Wh (105Ah)
- Warranty: 66 Months on Battery, 36 Months on Electronics
Input :
- Input Voltage Range (Normal Mode): 100V–290V
- Input Voltage Range (UPS Mode): 180V–270V
- Frequency: 50Hz
- Transfer Time (UPS Mode): <12ms
Output :
- Output Voltage (AC): 220Vrms
- Frequency: 50Hz
- Waveform: Sine wave
- Battery Charging: 15A
- Weight: 22 Kg
- Protections: Overload, Over/Under Voltage, Battery Deep Discharge, Battery Overcharge & Over Temperature
V-Smart 150045
Designed for large homes and small commercial spaces, the V-Smart 150045 delivers 1200W pure sine wave output for consistent, high-efficiency power backup.
Key Features:
- Dimensions (HxLxW): 327 x 417 x 340 mm
- Capacity: 1200W / 1500VA
- Full Load Backup: 1200W / 1 hr
- DC Voltage: 25.6 Vdc
- Battery Type: LiFePO4
- Battery Capacity (Wh): 1152Wh (45Ah)
- Warranty: 66 Months on Battery, 36 Months on Electronics
Input :
- Input Voltage Range (Normal Mode): 100V–290V
- Input Voltage Range (UPS Mode): 180V–270V
- Frequency: 50Hz
- Transfer Time (UPS Mode): <12ms
Output :
- Output Voltage (AC): 220Vrms
- Frequency: 50Hz
- Waveform: Sine wave
- Battery Charging: 15A
- Weight: 35 Kg
- Protections: Overload, Over/Under Voltage, Battery Deep Discharging, Battery Over Charge & Over Temperature
V-Smart 1500105
Heavy-duty lithium UPS built for longer backup durations, ideal for small enterprises and high-load homes.
Key Features:
- Dimensions (HxLxW): 327 x 417 x 340 mm
- Capacity: 1200W / 1500VA
- Full Load Backup: 1200W / 2 hrs 15 min
- DC Voltage: 25.6 Vdc
- Battery Type: LiFePO4
- Battery Capacity (Wh): 2688Wh (105Ah)
- Warranty: 66 Months on Battery, 36 Months on Electronics
Input :
- Input Voltage Range (Normal Mode): 100V–290V
- Input Voltage Range (UPS Mode): 180V–270V
- Frequency: 50Hz
- Transfer Time (UPS Mode): <12ms
Output :
- Output Voltage (AC): 220Vrms
- Frequency: 50Hz
- Waveform: Sine wave
- Battery Charging: 15A
- Weight: 42 Kg
- Protections: Overload, Over/Under Voltage, Battery Deep Discharging, Battery Over Charge & Over Temperature
V-Smart 200060
Powerful lithium UPS built for businesses requiring continuous operations, offering excellent reliability and faster charging.
Key Features:
- Dimensions (HxLxW): 327 x 417 x 340 mm
- Capacity: 1600W / 2000VA
- Full Load Backup: 1600W / 1 hr
- DC Voltage: 25.6 Vdc
- Battery Type: LiFePO4
- Battery Capacity (Wh): 1536Wh (60Ah)
- Warranty: 66 Months on Battery, 36 Months on Electronics
Input :
- Input Voltage Range (Normal Mode): 100V–290V
- Input Voltage Range (UPS Mode): 180V–270V
- Frequency: 50Hz
- Transfer Time (UPS Mode): <12ms
Output :
- Output Voltage (AC): 220Vrms
- Frequency: 50Hz
- Waveform: Sine wave
- Battery Charging: 15A
- Weight: 38 Kg
- Protections: Overload, Protection Over & Under Voltage, Battery Deep Discharging, Battery Over Charge & Over Temperature
V-Smart 2000105
Built for heavier loads and longer usage, this UPS can power critical operations with extended battery support.
Key Features:
- Dimensions (HxLxW): 327 x 417 x 340 mm
- Capacity: 1600W / 2000VA
- Full Load Backup: 1600W / 1 hr 45 min
- DC Voltage: 25.6 Vdc
- Battery Type: LiFePO4
- Battery Capacity (Wh): 2688Wh (105Ah)
- Warranty: 66 Months on Battery, 36 Months on Electronics
Input :
- Input Voltage Range (Normal Mode): 100V–290V
- Input Voltage Range (UPS Mode): 180V–270V
- Frequency: 50Hz
- Transfer Time (UPS Mode): <12ms
Output :
- Output Voltage (AC): 220Vrms
- Frequency: 50Hz
- Waveform: Sine wave
- Battery Charging: 15A
- Weight: 43 Kg
- Protections: Overload, Protection Over & Under Voltage, Battery Deep Discharging, Battery Over Charge & Over Temperature
V-Smart 250075
Industry-grade lithium UPS ideal for continuous, high-demand backup for factories, large offices, and industrial use.
Key Features:
- Dimensions (HxLxW): 327 x 417 x 340 mm
- Capacity: 2000W / 2500VA
- Full Load Backup: 2000W / 1 hr
- DC Voltage: 25.6 Vdc
- Battery Type: LiFePO4
- Battery Capacity (Wh): 1920Wh (75Ah)
- Warranty: 66 Months on Battery, 36 Months on Electronics
Input :
- Input Voltage Range (Normal Mode): 100V–290V
- Input Voltage Range (UPS Mode): 180V–270V
- Frequency: 50Hz
- Transfer Time (UPS Mode): <12ms
Output :
- Output Voltage (AC): 220Vrms
- Frequency: 50Hz
- Waveform: Sine wave
- Battery Charging: 15A
- Weight: 43 Kg
- Protections: Overload, Protection Over & Under Voltage, Battery Deep Discharging, Battery Over Charge & Over Temperature
V-Smart 2500105
Highest capacity V-Smart series UPS, built for the most demanding environments where extended runtime and durability are critical.
Key Features:
- Dimensions (HxLxW): 327 x 417 x 340 mm
- Capacity: 2000W / 2500VA
- Full Load Backup: 2000W / 1 hr 20 min
- DC Voltage: 25.6 Vdc
- Battery Type: LiFePO4
- Battery Capacity (Wh): 2688Wh (105Ah)
- Warranty: 66 Months on Battery, 36 Months on Electronics
Input :
- Input Voltage Range (Normal Mode): 100V–290V
- Input Voltage Range (UPS Mode): 180V–270V
- Frequency: 50Hz
- Transfer Time (UPS Mode): <12ms
Output :
- Output Voltage (AC): 220Vrms
- Frequency: 50Hz
- Waveform: Sine wave
- Battery Charging: 15A
- Weight: 45 Kg
- Protections: Overload, Protection Over & Under Voltage, Battery Deep Discharging, Battery Over Charge & Over Temperature
